Unleash the NanoFrazor’s potential! Packed with advanced features, this nanofabrication tool offers versatility. Tailor your setup with customizable modules, empowering you to craft the ideal system for your unique research requirements. Explore the boundless possibilities at your fingertips.
Advanced Lithography
Capabilities
Enables complex nanofabrication tasks.
High Resolution
and Precision
Provides accurate patterning at the nanoscale.
Versatile Applications
Suitable for a wide range of research and development activities.
User-friendly Interface
Simplifies the process of designing and executing nanolithography patterns.
Robust and
Reliable Design
Ensures consistent performance and longevity.
Damage-free Lithography
No damage from charged particles, no proximity effects, and clean lift-off.
Compatibility
Works with all
standard pattern
transfer methods.
Unique Thermal Cantilevers
Integrated microheater and distance sensor for cost-effectiveness.
Modules
Customizable
Configuration
Empowering users with flexibility: With 3 lithography modules, 3 housing options available, and 5 software packages, you can configure the NanoFrazor to your needs.
The 3 Housing
Options
Tabletop: Very compact housing solution that fits in every lab.
Stand Alone Housing: The most robust housing solution, that protect the NanoFrazor from external factors like acoustic noise and vibrations.
Glovebox: Put your NanoFrazor in a Glovebox, for NanoFrabrication in a controller gas environment.
The 3 Lithography
Modules
Single tip t-SPL: For high-resolution patterning, grayscale with un matched resolution, marker-less overlay local annealing.
Decapede: For all of the above with 10 times the throughput.
Direct Laser Sublimation: 1 um resolution patterning with higher throughput, and even more power for local annealing.
The NanoFrazor Software
and its Options
The NanoFrazor software guides the user through the system setup, layout import, and patterning. The beginner users feels comfortable with the simple user interface, while the advanced users can control all patterning parameters via the advanced settings panels. Advanced software modules are available and can be added to any software installation:
Grayscale patterning: import grayscale design and let the advanced depth feedback write them into your resist
Smart splitting:
Automated Overlay:
Termo chemical lithography (discuss about other possible names: Beyond lithography, or beyond t-SPL):
Upgradable
Modules
Begin with ease and expand as needed – NanoFrazor allows users to start with a simpler configuration and seamlessly integrate additional modules over time. This scalable approach ensures adaptability to evolving research demands.
